Let’s take a look at this easy crackme made by toasterbirb. You can also download it here; the password is crackmes.one. Let’s unzip it and see what we have inside:
1
2
3
4
5
sh1r4s3@amanita[/tmp/argc]% ls -l
total 20
-rw-rw-r-- 1 sh1r4s3 sh1r4s3 18608 Jul 5 15:16 argc
sh1r4s3@amanita[/tmp/argc]% file argc
argc: ELF 64-bit LSB pie executable, x86-64, version 1 (SYSV), dynamically linked, interpreter /lib64/ld-linux-x86-64.so.2, for GNU/Linux 3.2.0, with debug_info, not stripped
OK, we have an ELF file with debug info, huh, the file isn’t stripped. What external functions does this program use?
1
2
3
4
sh1r4s3@amanita[/tmp/argc]% nm -u argc | grep ' *U'
U __libc_start_main@GLIBC_2.34
U puts@GLIBC_2.2.5
U strcmp@GLIBC_2.2.5
The set is quite simple: puts(3) to print a string and strcmp(3) to compare two strings. The program is probably using strcmp(3) to compare input with something. Let’s give it a shot and run the program:
1
2
sh1r4s3@amanita[/tmp/argc]% ./argc
please try again and make sure to give the correct amount of arguments („ᵕᴗᵕ„)
Alright… but how many arguments do we need to provide? It’s time to blow the dust off our disassembler. I’ll use the radare2 tool but the reader can use a tool of their choice – objdump, gdb. First things first, I want to run the full analysis of the code (aaa) and get the call graph:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
┌────────────────────┐ ┌────────────────────┐ ┌────────────────────┐
│ dbg._start │ │ main │ │ entry.fini0 │
└────────────────────┘ └────────────────────┘ └────────────────────┘
t t t
│ │ │
┌──┘ │ │
│ ┌────────────│ │
│ │ └────────────┐ │
│ │ │ ┌────────────│
│ │ │ │ └────────────┐
│ │ │ │ │
┌───────────────────────────┐ ┌────────────────────┐ ┌────────────────────┐ ┌────────────────────┐ ┌────────────────────┐
│ reloc.__libc_start_main │ │ sym.imp.strcmp │ │ sym.imp.puts │ │ fcn.00001050 │ │ fcn.00001110 │
└───────────────────────────┘ └────────────────────┘ └────────────────────┘ └────────────────────┘ └────────────────────┘
On the left side we have our typical libc entry point from crt0.o or crt1.o. In the middle is application’s entry point – main() function. On the right side, we have finalization code from crtn.o. Generally, we should focus on the middle column since for developers, main() is the entry point. From the call graph we can see that main() function uses only 2 external functions: strcmp() and puts(), nothing new. From this information we can conclude that the original C code, most likely contains all the logic in one function – main(). Let’s dive into the main() function:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
[0x000010e0]> pdf @main
;-- section..text:
; ICOD XREF from dbg._start @ 0x10f8(r)
┌ 81: int main (uint32_t argc, char **s2);
│ `- args(rdi, rsi)
│ 0x00001080 f30f1efa endbr64 ; [13] -r-x section size 377 named .text
│ 0x00001084 53 push rbx
│ 0x00001085 83ff03 cmp edi, 3 ; argc
│ ┌─< 0x00001088 7539 jne 0x10c3
│ │ 0x0000108a 488b4610 mov rax, qword [rsi + 0x10] ; argv
│ │ 0x0000108e 488b7e08 mov rdi, qword [rsi + 8] ; const char *s1
│ │ 0x00001092 4889c6 mov rsi, rax ; const char *s2
│ │ 0x00001095 e8d6ffffff call sym.imp.strcmp ; int strcmp(const char *s1, const char *s2)
│ │ 0x0000109a 89c3 mov ebx, eax
│ │ 0x0000109c 85c0 test eax, eax
│ ┌──< 0x0000109e 7415 je 0x10b5
│ ││ 0x000010a0 488d3dd50f.. lea rdi, str.wrong_passwords... ; 0x207c ; "wrong passwords..." ; const char *s
│ ││ 0x000010a7 e8b4ffffff call sym.imp.puts ; int puts(const char *s)
│ ││ ; CODE XREF from main @ 0x10cf(x)
│ ┌───> 0x000010ac bb01000000 mov ebx, 1
│ ╎││ ; CODE XREF from main @ 0x10c1(x)
│ ┌────> 0x000010b1 89d8 mov eax, ebx
│ ╎╎││ 0x000010b3 5b pop rbx
│ ╎╎││ 0x000010b4 c3 ret
│ ╎╎││ ; CODE XREF from main @ 0x109e(x)
│ ╎╎└──> 0x000010b5 488d3da50f.. lea rdi, str.correct______ ; 0x2061 ; "correct! (\u02f6\u1d54 \u1d55 \u1d54\u02f6)" ; const char *s
│ ╎╎ │ 0x000010bc e89fffffff call sym.imp.puts ; int puts(const char *s)
│ └────< 0x000010c1 ebee jmp 0x10b1
│ ╎ │ ; CODE XREF from main @ 0x1088(x)
│ ╎ └─> 0x000010c3 488d3d3e0f.. lea rdi, str.please_try_again_and_make_sure_to_give_the_correct_amount_of_arguments___ ; 0x2008 ; "please try again and make sure to give the correct amount of arguments (\u201e\u1d55\u1d17\u1d55\u201e)" ; const char *s
│ ╎ 0x000010ca e891ffffff call sym.imp.puts ; int puts(const char *s)
└ └───< 0x000010cf ebdb jmp 0x10ac
We know (from x86_64 Linux psABI) that rdi has the first argument and rsi has the second one. That is, rdi is int argc and rsi is char **argv. At 0x00001085 we see that the program compares argc against 3. If the number of cmdline arguments is not 3, the program will jump to 0x000010c3 and output a message "please try again and make sure to give the correct amount of arguments (\u201e\u1d55\u1d17\u1d55\u201e)" which we already saw. OK, that’s nice, now we got to know how many arguments we have to pass – two (argv[0] is the command i.e. the program’s name).
Let’s take a look at the alternative branch, past the jne instruction. In this branch the program compares 2 arguments – second and third. At 0x0000109e the program checks for the result and if the strings are matching it jumps to 0x000010b5 and outputs a message that we’ve passed the test: "correct! (\u02f6\u1d54 \u1d55 \u1d54\u02f6)", otherwise it outputs "wrong passwords..." message and returns with the error 1. Looks to be pretty easy, let’s try to use the obtained knowledge to solve this crackme:
1
2
sh1r4s3@amanita[/tmp/argc]% ./argc lol lol
please try again and make sure to give the correct amount of arguments („ᵕᴗᵕ„)
Hmm… somehow it didn’t work. The easiest way to understand what’s wrong is to observe the program at runtime through a debugger. I’ll use gdb for that purpose. The plan is to break at main() and follow the initial instructions. Let’s do this:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
(gdb) b main
Breakpoint 1 at 0x1080
(gdb) r lol lol
Starting program: /tmp/argc/argc lol lol
[snap]
Breakpoint 1, 0x0000555555555080 in main ()
(gdb) x/16i $pc
=> 0x555555555080 <main>: endbr64
0x555555555084 <main+4>: push %rbx
0x555555555085 <main+5>: cmp $0x3,%edi
0x555555555088 <main+8>: jne 0x5555555550c3 <main+67>
0x55555555508a <main+10>: mov 0x10(%rsi),%rax
0x55555555508e <main+14>: mov 0x8(%rsi),%rdi
0x555555555092 <main+18>: mov %rax,%rsi
0x555555555095 <main+21>: call 0x555555555070 <strcmp@plt>
0x55555555509a <main+26>: mov %eax,%ebx
0x55555555509c <main+28>: test %eax,%eax
0x55555555509e <main+30>: je 0x5555555550b5 <main+53>
0x5555555550a0 <main+32>: lea 0xfd5(%rip),%rdi # 0x55555555607c
0x5555555550a7 <main+39>: call 0x555555555060 <puts@plt>
0x5555555550ac <main+44>: mov $0x1,%ebx
0x5555555550b1 <main+49>: mov %ebx,%eax
0x5555555550b3 <main+51>: pop %rbx
Here, I’ve set a breakpoint at main() and started the program with 2 arguments. Let’s set a breakpoint at 0x555555555085 where cmp instruction is located, as this is our first branching point and then let’s see what happens next.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
(gdb) b *0x555555555085
Breakpoint 2 at 0x555555555085
(gdb) c
Continuing.
Breakpoint 2, 0x0000555555555085 in main ()
(gdb) x/4i $pc
=> 0x555555555085 <main+5>: cmp $0x3,%edi
0x555555555088 <main+8>: jne 0x5555555550c3 <main+67>
0x55555555508a <main+10>: mov 0x10(%rsi),%rax
0x55555555508e <main+14>: mov 0x8(%rsi),%rdi
(gdb) ni
0x0000555555555088 in main ()
(gdb) p $eflags
$8 = [ CF AF SF IF ]
(gdb) ni
0x00005555555550c3 in main ()
(gdb) p/x $edi
$10 = 0x1
Well, that’s odd! If you wonder what’s happened here, here’s the explanation:
- We provided 2 arguments, so
argcshould be3.ediregister containsargcand we expectcmpinstruction to setZFflag so thatjnewill not jump and we will proceed tostrcmp. - However, the
cmpinstruction has failed and we don’t seeZFflag has been set ineflags. - Because of that we made a jump to
0x5555555550c3 <main+67>, where the program prints an error message. - Upon checking
ediit turned out that it has1instead of3which doesn’t make any sense, right?
Even though the crackme looks easy, straightforward I’d say, it has a trick. The trick is that, usually, libc provides crt1.o object file, however, nothing can stop us to use our own crt1.o with modified _start() function. The trick is that _start() function prepares the arguments for main(). As you probably guessed _start() has been modified and does something with the arguments for main(). Let’s take a look at it, shall we? The following is disassembled code of _start() in radare2:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
[0x000010e0]> pdf @sym._start
;-- entry0:
;-- _start:
;-- rip:
┌ 37: dbg._start (int64_t arg3);
│ `- args(rdx)
│ 0x000010e0 58 pop rax ; start.S:57 ; void _start();
│ 0x000010e1 d0e8 shr al, 1
│ 0x000010e3 50 push rax
│ 0x000010e4 31ed xor ebp, ebp ; start.S:62
│ 0x000010e6 4989d1 mov r9, rdx ; start.S:78 ; arg3
│ 0x000010e9 5e pop rsi ; start.S:84
│ 0x000010ea 4889e2 mov rdx, rsp ; start.S:87
│ 0x000010ed 4883e4f0 and rsp, 0xfffffffffffffff0 ; start.S:89
│ 0x000010f1 50 push rax ; start.S:92
│ 0x000010f2 54 push rsp ; start.S:96
│ 0x000010f3 4531c0 xor r8d, r8d ; start.S:99
│ 0x000010f6 31c9 xor ecx, ecx ; start.S:100
│ 0x000010f8 488d3d81ff.. lea rdi, [main] ; start.S:103 ; 0x1080
└ 0x000010ff ff15d32e0000 call qword [reloc.__libc_start_main] ; start.S:115 ; [0x3fd8:8]=0
From this assembly code we see that at the last line _start() is calling libc function which will, eventually, call main(). This libc function has the following signature:
1
2
3
4
__libc_start_main (int (*main) (int, char **, char **),
int argc, char *argv,
void (*init) (void), void (*fini) (void),
void (*rtld_fini) (void), void *stack_end)
In this post I’m not going to explain everything but here readers can find more details. The important part is that argc is the second argument and hence, according to psABI, it should be in the rsi register when we pass it to the __libc_start_main() function. For _start(), in contrary, the arguments are placed into stack. The first argument is argc which is getting popped into rax in the beginning of the function. It gets shifted to the right by 1 bit and later popped into rsi. Later, the code is not changing rsi, so this value goes into our main(). Also nothing is changing argv, so it gets transferred, unchanged, into main(). Taking into account all of that information we can finally try to crack this crackme! For that we need to provide the number of arguments which will turn into 3 after shifting 1 bit right, that is 6. The math is as follows: 0b110 = program name + 5 arguments = 6 because 0b110 >> 1 = 0b011 = 3. Let’s try it out:
1
2
sh1r4s3@amanita[crackmes/argc]% ./argc lol lol 1 2 3
correct! (˶ᵔ ᵕ ᵔ˶)
That’s it!
